JetFog Livestock Cooling Systems
The JetFog low pressure fog system creates a fine fog at line pressure for cooling or humidity. With an output of 5.8 liters per hour, the JetFog produces a hollow cone of very fine mist droplets at a minimum operating pressure of 50psi. With an average particle size of 80 microns, the JetFog nozzle is perfect for reducing the temperature without wetting the ground or your animals.
 |  |
The JetFog nozzles are available with either a barbed or threaded connection for a variety of installation options. The barbed JetFog nozzle can be punched into PE tubing for easy installation. The threaded JetFog nozzle can be inserted into PVC or even riser assemblies.
Let Dramm design your system.
The JetFog nozzle can be combined with our PolyRail product and black PE tubing for easy installation without sagging. Dramm solenoid valves and the MistTime misting controller complete the package to form an entire cooling system.
For more information download the PDF Brochure and this article discussing the system further.
Contact us via e-mail or by phone at the numbers listed to the left.
JetFog Barbed Nozzle
The JefFog nozzle offers a very fine spray (80 micron) between 50-70 psi. Available in a barbed or threaded inlet with single or multiple outlets. Flow per tip is 5.8 lph (1.5 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFSB | - | JetFog Barbed Nozzle | BROCHURE | MANUAL | - |
JetFog Threaded Nozzle
The JefFog nozzle offers a very fine spray (80 micron) between 50-70 psi. Available in a barbed or threaded inlet with single or multiple outlets. Flow per tip is 5.8 lph (1.5 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFST | - | JetFog Threaded Nozzle | BROCHURE | MANUAL | - |
JetFog 2 way Barbed
Two outlet nozzle with barbed inlet. Flow rate is 11.6 lph (3 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFB2 | - | JetFog 2 way Barbed | BROCHURE | MANUAL | - |
JetFog 4 way Barbed
Four outlet nozzle with barbed inlet. Flow rate is 23.2 lph (6 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFSB4 | - | JetFog 4 way Barbed | BROCHURE | MANUAL | - |
JetFog 5 way Barbed
Five outlet nozzle with barbed inlet. Flow rate is 29 lph (7.5 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFSB5 | - | JetFog 5 way Barbed | BROCHURE | MANUAL | - |
JetFog 4 way Threaded
Four outlet nozzle with threaded inlet. Flow rate is 23.2 lph (6 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFST4 | - | JetFog 4 way Threaded | BROCHURE | MANUAL | - |
JetFog 5 way Threaded
Five outlet nozzle with threaded inlet. Flow rate is 29 lph (7.5 gph).
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JFST5 | - | JetFog 5 way Threaded | BROCHURE | MANUAL | - |
JetFog Greenhouse Manual
Installation and care manual for JetFog nozzles.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| Manual | - | JetFog Greenhouse Manual | BROCHURE | MANUAL | - |
Replacement Nozzle for JetFog
Replacement nozzle tip for JetFog nozzle. Press-fit connection.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-525 | - | Replacement Nozzle for JetFog | BROCHURE | MANUAL | - |
Blank Nozzle for JetFog
Blank nozzle tip to prevent spray from any JetFog outlet. Press-fit connection.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-524 | - | Blank Nozzle for JetFog | BROCHURE | MANUAL | - |
2 way cross for JetFog
Two way cross for JetFog Nozzle. Press fit connection.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-2CROSS | - | 2 way cross for JetFog | BROCHURE | MANUAL | - |
4 way cross for JetFog
Four way cross for JetFog Nozzle. Press fit connection.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-4CROSS | - | 4 way cross for JetFog | BROCHURE | MANUAL | - |
Replacement ADV Diaphragm for JetFog
Replacement diaphragm for JetFog Anti Drip Device. Silicone. Use JF-WRENCH-C to access diaphragm and reseat new diaphragm.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-560 | - | Replacement ADV Diaphragm for JetFog | BROCHURE | MANUAL | - |
JetFOG Nozzle Service Kit
Includes JF-WRENCH & BLANK tool, 10 BLANK6, 5 JF-525, 3 JF-524, 5 JF-560
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-KIT | kit | JetFOG Nozzle Service Kit | BROCHURE | MANUAL | - |
JetFOG Wrench Tool w/ JetFOG Seat Tool
Combo set for disassembling and reassembling JetFOG nozzles easily.
| ITEM | SIZE | NAME | BROCHURE | MANUAL | SHIP WT. |
| JF-WRENCH-C | - | JetFOG Wrench Tool w/ JetFOG Seat Tool | BROCHURE | MANUAL | - |
