Watering Tools



In 1945 John Dramm invented the 400AL Waterbreaker. Designed to offer a soft, aerated flow for watering plants, this invention sparked a revolution in hand watering.

Since then, Dramm has offered innovation after innovation in hand watering. From specialized nozzles like the 1000PL Redhead and the 350PL Scree-Aire to durable, high flow valves, the Dramm Corporation offers a wide variety of specialty nozzles for the professional grower.

With over 65 years of experience in watering in horticulture, we have learned one thing, teaching someone to water properly is a difficult task. Watering in the greenhouse is as much an art as a science. We have created a series of videos offering training and tips on hand watering in the greenhouse.

In the future, we plan to offer more watering training videos and would welcome your suggestions.
Our second video on our series on hand watering describes the different tools available and suggests uses for each nozzle and valve combination.



For our offering in Europe please click here.

Individual products are detailed below. Please scroll down for a full listing.

400 Aluminum Water Breaker® Nozzle


The original full-flow shower head nozzle. Dramm's aluminum 400 Water Breaker provides fast, full-flow watering without damage to your plants or disturbing soil. Used and recommended daily by professional growers worldwide. Cast aluminum and hand machined with 3/4 inch brass hose threads. Invented, designed and manufactured in the U.S.A. since 1945.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
400AL 11.1 @ 40 PSI 5.1 oz 50 17 lbs

170 Aluminum Water Breaker® Nozzle


The 170AL Water Breaker is excellent for watering in areas with low water pressure or with systems which restrict total water volume. It is designed for small containers (hanging baskets), and when using fertilizer syphons. Adjust water flow to 50% of its possible volume. Cast aluminum with 3/4 brass hose threads. Manufactured in the U.S.A.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
170AL 7 @ 40PSI 1.6 oz 64 8

400PL Water Breaker® Nozzle


The 400PL Water Breaker provides fast, full-flow watering without damage to your plants. Patterned after the original 400 Aluminum water breaker , the 400PL is made from high-impact ABS plastic and aluminum to provide a lightweight alternative. Used by professional growers worldwide. Made in U.S.A. 3/4 hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
400PL 11.1 @ 40 PSI 1.3 oz 50 6 lbs

170PL Water Breaker® Nozzle


Patterned after the 170 Aluminum water breaker, the 170PL is an excellent choice for watering in areas with low water pressure or with systems which restrict total water volume. It is designed for small containers (hanging baskets). Adjust water flow to 50% of its possible volume. Made in the U.S.A. from ABS plastic. 3/4 hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
170PL 7 @ 40 PSI 4 lbs 64 4 lbs

480PL Plastic Fine Water Breaker® Nozzle


480 Plastic Water Breaker. Stainless steel disk. Micro-fine holes. Focused Pattern.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
480PL 7 @ 40 PSI 1.6 oz 64 8 lbs

480AL Aluminum Fine Water Breaker® Nozzle


480 Aluminum Water Breaker. Stainless steel disk. Micro-fine holes. Wider pattern.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
480AL 7 @ 40 PSI 1.6 oz 64 8 lbs

Screen-Aire Water Breaker® Nozzle


The Screen-Aire Water Breaker is designed to water nursery containers with a gentle, concentrated aerated flow of water. A fine-mesh screen and an array of internal components combine air and water to produce a very soft, unrestricted spray. Use a Dramm In-Line Hose Filter to keep the nozzle from clogging. Made in the U.S.A. 3/4 brass threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
350PL 18 @ 40 PSI 5.6 oz 25 10 lbs

1000PL Water Breaker® Nozzle


The 1000PL Redhead water breaker has over 1,000 micro holes that create an ultra-soft flower shower which will not disturb delicate soil or harm tender plants. Use with a Dramm In-Line Hose Filter to prevent clogging. Made in U.S.A. from ABS plastic and stainless steel.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
1000PL 7 @ 40 PSI 1.6 oz 50 6 lbs
1000PL-N 7 @ 40 PSI 1.6 oz 50 6 lbs
1000PL-W 7 @ 40 PSI 1.6 oz 50 6 lbs

750PL Fine Low Flow Water Breaker® Nozzle


The 750PL Water Breaker has 750 micro-holes for a fine pattern with a slightly reduced flow rate. The 750PL is perfect for light watering with a very soft pattern. Wider pattern.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
750PL 7 @ 40 PSI 1.6 oz 50 6 lbs

175 micron In-Line Hose Filter


The Dramm In-Line Hose Filter is for use with any Dramm hose nozzle, but highly recommended for the 1000PL Water Breaker and the 350AL Screen Aire. A stainless steel 175 micron (80 mesh) screen filters out unwanted dirt and debris.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
ILF-175 10 @ 40 PSI 2.8 oz 25 5 lbs

In-Line Wand Filter Element



175 micron element for the ILF-175.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
ILFE-175 element only 1 oz - -
ILF-080 8 @ 40 PSI 2.8 oz 25 5 lbs
ILFE-080 element only 1 oz - -

175 micron In-Line Hose Filter - Metric Threads


The Dramm In-Line Hose Filter is for use with any Dramm hose nozzle, but highly recommended for the 1000PL Water Breaker and the 350AL Screen Aire. A stainless steel 175 micron (80 mesh) screen filters out unwanted dirt and debris.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
72530M 10 @ 40 PSI 2.8 oz 25 5 lbs

Brass Hose Swivel


The Brass Hose Swivel is a live swivel that allows for unencumbered movement between the hose and attachements under pressure. Reduces hose twisting.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
72700 - 6.0 oz 12 8 lbs

Brass Rose - 4 Diameter


Our Brass Rose features an extra wide spray pattern, which allows you to increase the speed of hand watering. Available in a 4-inch diameter. Great for watering bedding plants, pots or market packs. 540B includes protective rubber guard and metric to inch hose thread converter. Made in Germany with 3/4 hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
540B 18-20 @ 40 PSI 8.7 oz 10 20 lbs

Plastic Fan Nozzle


The Dramm Plastic Fan Nozzle offers a medium flow in a rectangular pattern. Perfect for flats and plug trays.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
79001 5-7 gpm @ 40 PSI 2.7 oz 12 5 lbs.

High Pressure Wash Down Nozzle - 6 Long


The 6 Brass Wash Down Nozzle is a high-pressure nozzle perfect for washing down walkways or any area needing a quick cleaning. Made from heavy-duty cast brass. 3/4 hose thread.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
600B 7 @ 40 PSI 4 oz 24 10 lbs

Seedling Nozzle


The Seedling Nozzle allows you to water fragile plants, delicate seedlings or plant cuttings. This high-quality nozzle produces an extra fine, hollow cone mist pattern and sprays 1/2 gallon of water per minute. Made in the U.S.A. from solid brass. 3/4 hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
510 1/2 @ 40 PSI 2.7 oz 24 5 lbs

Fogg-It Nozzle - Super Fine


The Fogg-It Nozzle is designed for misting delicate seedlings or for raising humidity around wilting plants. This nozzle has three mist jets which create a conical spray pattern. Available in 4 different discharge rates. Made in the U.S.A. from solid brass. 3/4 hose threads. Available in 4 different flow rate sizes.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
610SF 1/2 GPM @ 40 PSI 4.2 oz 64 18 lbs

Fogg-It Nozzle - Fine



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
610F 1 GPM @ 40 PSI 4.2 oz 65 -
610L 2 GPM @ 40 PSI 4.2 oz 66 -
610H 4 GPM @ 40 PSI 4.2 oz 67 -

Adjustable Hose Nozzle


Our Adjustable Hose Nozzle is great for cleaning walkways, benches, equipment... just about anything! Twist the barrel to adjust the water pattern from a fine, cone-shaped spray to a powerful stream. Twist the barrel back and the water is off. Manufactured in the U.S.A. from brass. 3/4 hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
800 Variable 5.8 oz 24 9 lbs

Syphonject™


Syphonject - plastic siphon mixer. Our 20:1 ratio feeder syphons solution using a pressure drop created by the passing stream of water. The Syphonject is made from glass filled polypropylene and is very durable as well as corrosion resistant. An external check valve ensures that water does not fill the solution source and is easy to replace. The Syphonject is perfect for fertilizing and cleaning.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
22624 7 @ 40 PSI 8 oz 12 6 lbs

Handi-Grip™ Handle


The Handi-Grip Handle provides comfort when watering directly from your hose. It is also perfect for using with the Brass Rose or any of the Dramm Water Breakers. The six inch long grip is encased in a padded foam grip. Made in the U.S.A. from aluminum and brass. 3/4 male and female hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
106-G -- 2.3 oz 12 4 lbs

Handi-Reach™ Handle


Handi-Reach Handles are designed to eliminate the stretching and stooping associated with hand watering. Available in 16, 24, 30, 36, and 48-inch lengths, these rugged tools allow you to water hard-to-reach areas with ease. Made in the U.S.A. from extruded aluminum tubing, forged brass hose couplings and a comfort EPDM hand grip. 3/4 male and female hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
116-G -- 4.1 oz 12 4 lbs

24 Handi-Reach™ Handle



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
124-G -- 5.2 oz 12 5 lbs
130-G -- 5.8 oz 6 4 lbs
136-G -- 6.6 oz 6 4 lbs
148-G -- 8.1 oz 6 5 lbs

36 Hanging Basket Handle


Hanging Basket Handles offer a 90_ curve in the top of handle so you can water directly into a hanging basket. Available in 36 and 48-inch lengths, Use with any 170 series Water Breaker to water hanging baskets and window boxes. Made in the U.S.A. from extruded aluminum tubing, forged brass hose couplings and a comfort EPDM hand grip. 3/4 male & female hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
136-GB -- 6.5 oz 6 4 lbs

48 Hanging Basket Handle



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
148-GB -- 8.1 oz 6 5 lbs

Handi-Reach™ Color Handle



Upgrade to our colorized Handi-Reach Handles. These are the same heavy-duty extension handles as noted above, except they have a super comfortable foam hand grip and come in the color of your choice. Six bright colors are available in 16, 24 or 30-inch lengths. Choose from Red (RD), Orange (OR), Yellow (YL), Green (GN), Blue (BL) or Berry (BY)

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
116-GCM -- 4.3 oz 12 4 lbs
124-GCM -- 5.3 oz 12 4 lbs
130-GCM -- 5.9 oz 6 4 lbs

Hose Protector



The Hose Protector saves hose ends from unnecessary stress and strain. Utilizing a spring wound around a short length of hose, the Hose Protector connects between the faucet and your hose to prevent hose-end kinking and damage to hose couplings. This handy tool is made from zinc plated steel and heavy-duty, nickel plated brass. The Hose Protector has a 5/8 inch inside diameter. 3/4 inch male & female hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
HP-625 -- 4.4 oz 25 8 lbs

Hose Extender



The Hose Extender is a flexible 24 extension of your hose which can be used with any Dramm water tool. Great for hand watering! Just place our Brass Shut-Off on one end and a 400 Water Breaker on the other. Made in the U.S.A. from reinforced synthetic rubber and heavy-duty brass 3/4 connections. 5/8 inside diameter.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
HE-625 -- 8 oz 10 5 lbs

Brass Twisty Quick 5/8


The 625 and 675 Twisty Quick are 1/4 turn quick disconnects with hose barb fittings for use with blunt cut hoses. Secure hose to the fitting with a hose clamp (not provided). Can be used in any combination with 775M and 775F Twisty Quick. Made in Germany from forged brass. Order item 625 for 5/8 ID hose or item 675 for 3/4 ID hose.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
625 -- 3.9 oz 10 3 lbs

Brass Twisty Quick 3/4



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
675 -- 4.2 oz 10 3 lbs

Threaded Brass Twisty Quick - Male


The 775M & 775F Twisty Quick are 1/4 turn Quick Disconnects. Makes any threaded hose connection easy to couple/uncouple. Can be used in any combination with 625 & 675 Twisty Quick. Made in Germany from forged brass. 775M - 3/4 male hose thread, 775F - 3/4 female hose thread.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
775M -- 3.0 oz 10 3 lbs

Threaded Brass Twisty Quick - Female



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
775F -- 3.4 oz 10 3 lbs

Twisty Quick


Twisty Quick-- plastic quick connect hose adapter. Full water flow design. Our patended design is made from heavy-duty plastic. 3/4 male and female hose threads. Sold as a pair only.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
710 -- 2 oz 25 4 lbs

Brass Quick Disconnect


The 740 Brass quick connects offer full flow without water-stop.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
740 - 3.4 oz 25 6 lbs

Shut-Off Valve


Our #35 Shut-Off is designed to provide fingertip water control at the end of your garden hose. A simple quarter turn and the water is off-- even when your hands are wet! Engineered to withstand higher water pressures than ordinary inexpensive plastic valves. Made from heavy-duty plastic. 3/4 hose threads in the USA.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
35 13 gpm 1 oz 50 4 lbs

Twin Shut-Off Valve


Water two places at one time with the 235 Twin Shut-Off Valve! Connect the valve to your faucet to create two male connections-- with each connection independently controlled. A quarter turn of the handle and the water flow is shut off. Molded from high quality ABS plastic. 3/4 male and female hose threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
235 11 gpm 1.2 oz 24 3 lbs

Heavy Duty Plastic Shut-Off Valve


The 74 Shut-off valve is made from glass fille polypropylene to be very durable and corrosion resistant. More durable than other plastic valves, the 74 is lightweight and offers a full flow.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
74 18 gpm 1.4 oz 25 5 lbs

Brass Shut-Off Valve


Simply the best shut-off valve available. Dramm's #300 Brass Shut-Off Valve provides fingertip water control at the end of your greenhouse hose. A quarter turn of the large ergonomic handle and the water is off. Full water flow design. Made in the USA from brass, durable seals and a hard chrome plated ball to provide years of service. 3/4 threads.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
300 17 gpm 7.9 oz 25 14 lbs

Aluminum Shut-Off Valve


The 300AL is exactly the same as the 300 Brass, but made from machined aluminum. Lighter weight that its cousin, it is just as durable. Depending on water quality and other fittings used, corrosion may result.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
300AL 17 gpm - 25 -

Touch N' Flow Pro™


The 65 Touch N'Flow Pro Trigger Valve offers durability and high flow in a trigger valve. With 11 gpm output and a long life, the 65 TNF Pro allows for flexibility when watering.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
65 11 gpm max - 25 -

2 Liter Watering Can


The unique spout design and excellent balance make this watering can perfect for indoor use. Houseplant watering is easy with the far reaching spout. Two liter (1/2 gallon) capacity. Complete with a detachable plastic rose. Made from high-grade, durable plastic in red, yellow, green, and blue. Made in Switzerland.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
B2L -- 9.6 oz 10 9 lbs

5 Liter Watering Can


Our 5 liter watering can features an extra long spout with a brass rose. The rain-like water pattern arches upward and softly falls upon plants. This gentle sprinkle is unequaled for applying fertilizer to foliage. Detachable brass rose included. Available in red, yellow, green, and blue. 1 1/3 gallon capacity. Made in Switzerland.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
B5L -- 1 lb 9.6 oz 10 21 lbs

7 Liter Watering Can


Designed for and used by professional growers for over 100 years. Now manufactured from 1/8 injection molded plastic so they won't rust, leak or corrode. Available in red, yellow, green, and blue. Perfectly balanced for indoor and outdoor use. Comes standard with large plastic rose. 1 3/4 gallon capacity. Made in Switzerland.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
B7L -- 1 lb 12 oz 10 22 lbs

10 Liter Watering Can


Our largest watering can holds over 2 gallons and is engineered for years of use. A detachable angle spout ensures that your plants receive water where you want it. Perfect for Interior Plantscape professionals. Roses sold seperately. Available in red and green. 2 1/2 gallon capacity. Made in Switzerland.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
B10L -- 2 lbs 5.6 oz 6 18 lbs

2 Liter Replacement Rose


Replacement roses and elbows for Dramm Watering Cans. Specify color code when ordering: Red (RD), Yellow (YL), Green (GN), Blue (BL)

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
2LR-_ _ -- -- 1 1 lbs

5 Liter Replacement Rose



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
5LR-_ _ -- -- 1 1 lbs
7LR-_ _ -- -- 1 1 lbs
10LR-_ _ -- -- 1 1 lbs
10LS-_ _ -- -- 1 1 lbs

ColorStorm™ Professional Rubber Hose


ITEM GPM WEIGHT CASE PACK CASE WEIGHT
- - - - -

ColorStorm™ Hose 5/8 in 50 ft



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
17003 - - - -
17203 - - - -
17303 - - - -
17999 - - - -
17013 - - - -
17213 - - - -
17313 - - - -
17989 - - - -

Nickel Plated, Machined Brass Hose Fittings for ColorStorm™ Hose



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
- - - - -
MCP20124 - - - -
MCP20248 - - - -
MCP20124 - - - -
MCP20249 - - - -
19242 - - - -
19178 - - - -

DrammPress Frame


The DrammPress fits Dramm ColorStorm hose with our professional fittings by hand or using a cordless drill. The Dramm Crimper can be fitted with either 5/8 or 3/4 jaws (sold separately). Works with all Dramm ColorStorm fittings and ferrules.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
DP-FRAME - - ea -

DrammPress 5/8 Jaws



Choose either jaw size to fit Dramm ColorStorm hoses. Either jaw fits the DrammPress (sold separately).

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
DP-J625 - - ea -
DP-J750 - - ea -

How to use the DrammPress



ITEM GPM WEIGHT CASE PACK CASE WEIGHT
How To - - - -

Fitting/Ferrule Set 5/8 in Male 12 pk



Fitting and Ferrule set for use with the DrammPress Hose Crimper and ColorStorm Hose

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
10-17810 - - 12 2 lbs
10-17815 - - 12 2 lbs
10-17820 - - 12 2 lbs
10-17825 - - 12 2 lbs
10-17830 - - 12 2 lbs
10-17840 - - 12 2 lbs

One Touch™ Valve


The OneTouch Valve offers thumb-tip control of your water flow. With 11 gpm output and a long life, the OneTouch Valve offers flexibility when watering.

ITEM GPM WEIGHT CASE PACK CASE WEIGHT
14700 11 gpm @ 40 psi - 12 -
